Fabrication benefits
- easy compatibility with the profiles of the Economy 50 series
- well-known glazing bead fixing technology
- individually combinable profiles
Technical information
System basic depth50 mm
Uf value of frame (≥)6 W/(m²·K)
Max. height2400 mm
Max. width1840 mm
Max. glass/panel thickness24 mm
Area of applicationInternal use, Residential projects, Residential projects, Commercial projects, Doors
Surface finishesRAL, Powder, Paint
Ud value of door (≥)2 W/(m²·K)
Max. vent weight100 kg
Min.-max. height1900…2400 mm
Min.-max. width250…1840 mm
Max. clear opening dimension (w x h)1800 x 2400 mm
Min. clear opening dimension (w x h)250 x 1900 mm
Min. face width51 mm
Min.-max. glass/panel thickness5…24 mm
Barrier-free (≤) 20 mmYes
Thick door leaf50 mm
Type of designSingle-vent, Double-vent, Single-vent with toplight and side section, Double-vent with toplight and side section
Vent optionFlush-fitted, Face-fitted
Infill typeInsert panel infill, Door infill, leaf-enclosing on two sides
Door thresholdAutomatic door gasket, Flat door threshold, Easy-access door threshold
Special applicationsSheet metal clad door
Fitting materialSteel, Stainless steel
Neutral-colour fittingYes
Fittings installationSurface-mounted door hinge, Barrel hinge
Opening typeSingle and double-vent
DIN directionDIN LH / RH
Door swingFlush-fitted, Rebated
Door closer typeTop closers
CAD data
Jansen Art‘15
Test documents
| Document type | Test type | Result | Classification | Document no. / Download |
|---|---|---|---|---|
| Gutachterliche Stellungnahme | Schallmessung | Rw=24…44dB | Rw=24…44dB | View onlineDownload |
| Gutachterliche Stellungnahme | Schallmessung | Rw=24…44dB | Rw=24…44dB | View onlineDownload |
| Gutachterliche Stellungnahme | Schallmessung | Rw=24…44dB | Rw=24…44dB | View onlineDownload |
