Fabrication benefits
- ift passive house compatible with centre gasket
- Special vent frame profile for the use of adhesive technology
- High-quality EPDM functional gaskets machine-rolled in the factory, can be welded
- Due to a special, patented technology for welding the profiles, the gaskets do not require any additional processing
- Glazing bridge with self-locating clamp for secure and easy installation
- Cliphook on the double-vent profiles as a positioning aid for simple installation and central screw connection
- Due to 5 mm gasket clearance between the outer and vent frames, the vent rebate gasket does not need to be notched in the turn/tilt mechanism pivot area
- Identical system dimensions, e.g. glass deduction, when fabricating with rebate gasket and centre gasket
Technical information
System basic depth82 mm
Min. face width120 mm
Uf value of frame (≥)0.96 W/(m²·K)
Max. glass/panel thickness52 mm
Max. vent width1500 mm
Max. vent height2600 mm
Max. sound reduction Rwp47 dB(A)
Air permeabilityClass 4
WatertightnessClass 9A
Burglar resistanceUp to RC2
Wind load resistanceClass C5 / B5
Max. vent weight250 kg
Min.-max. vent height400…2600 mm
Min.-max. vent width400…1500 mm
Min.-max. glass/panel thickness24…52 mm
Surface finishesTopAlu, Decorative foils, AutomotiveFinish
Documentation
Schüco Corona CT 70
Schüco TopAlu
Schüco LivIng
Schüco Alu Inside SI 82
Schüco Corona SI 82
Test documents
| Document type | Test type | Result | Classification | Document no. / Download |
|---|---|---|---|---|
| Prüfbericht | Fähigkeit zur Freigabe | Anforderung erfüllt | Anforderung erfüllt | View onlineDownload (pdf, 654.7 KB) |
| Prüfbericht | Einbruchhemmung | Anforderung erfüllt | Anforderung erfüllt | View onlineDownload (pdf, 922.1 KB) |
| Prüfbericht | Wärmedurchgangskoeffizient | 1,3 W/(m²K) | 1,3 W/(m²K) | View onlineDownload (pdf, 2.7 MB) |
| Prüfbericht | Einbruchhemmung | Anforderung erfüllt | Anforderung erfüllt | View onlineDownload (pdf, 1.1 MB) |
| Gutachterliche Stellungnahme | Einbruchhemmung Einbruchhemmung |
RC 2 RC2 |
View onlineDownload (pdf, 9.1 MB) | |
| Gutachterliche Stellungnahme | Windwiderstandsfähigkeit | GAS stat. Bemessunggl. 06.2017 | GAS stat. Bemessunggl. 06.2017 | View onlineDownload (pdf, 316.9 KB) |
| Produktpass | Zulassung | View onlineDownload (pdf, 1.1 MB) | ||
| Produktpass | Zulassung | View onlineDownload (pdf, 1.1 MB) |
